ESD7504MUTAG ESD diode LOW CAP ESD Protection

Product Details:

Place of Origin:	United States
Brand Name:	onsemi
Model Number:	ESD7504MUTAG

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	USD 0.01-20/piece
Packaging Details:	SOT-23
Delivery Time:	5-8 work days
Payment Terms:	T/T

Contact Now Chat Now

Detailed Product Description

Installation Style:	SMD/SMT	Number Of Channels:	4 Channel
Encap300Vsulation:	Reel，Cut Tape，MouseReel	Series:	ESD7504
Unit Weight:	32mg
Highlight:	smd bias resistor transistor , smt bias resistor transistor

Manufacturer: onsemi
Product category: ESD protection diode /TVS diode
Polarity: Unidirectional
Number of channels: 4 Channel
Operating voltage: 3.3 V
Termination type: SMD/SMT
Clamping voltage: 13.7 v.
Breakdown voltage: 4 V
Package/box: UDFN-10
Ipp-peak pulse current: 16 A
Peak pulse power consumption (pppm): 30 w
Cd-diode capacitance: 0.55pf.
Vesd-electrostatic discharge voltage contact: 15 kV
Vesd-electrostatic discharge voltage air gap: 15 kV
Product type: ESD Suppressors
Minimum operating temperature:-55 C.
Maximum operating temperature:+125c
Series: ESD7504
Package: Reel
Package: cuttape
Encapsulation: MouseReel
Trademark: onsemi
Sub-category: TVs Diodes/ESD suppression Diodes
Unit weight: 32 mg

Tag:

Contact Person: Hefengxin

Tel: +8613652326683

Send your inquiry directly to us
